Verify that the cable management arm (CMA) retracts without binding.
Note:
To pull the green release tab, place your finger in the center of the tab, not
on the end, and apply pressure as you pull the tab toward the front of the
server.
b. Continue pushing the server into the rack until the slide-rail locks (on the front of the
server) engage the slide-rail assemblies.
You hear an audible click when the server is in the normal rack position.
2. Do one of the following:
• If you previously removed the CMA, proceed to the next section to reinstall it. See
Install the Cable Management Arm (Optional).
• If you did not remove or purchase the optional cable management arm, retract the
rack anti-tilt mechanism back to its normal position.
Install the Cable Management Arm (Optional)
Follow this procedure to install the cable management arm (CMA), which you can use to
manage cables connected to the back of the server.
Chapter 6
Install the Cable Management Arm (Optional)
6-5
