Note:
An antistatic wrist strap is not included in the Accessory Kit for the server.
However, antistatic wrist straps might be included with options and
components.
Remove the Server Top Cover
Remove the top cover to service components inside the server.
1. To service non-hot pluggable components, ensure that AC power cords are disconnected
from the server power supplies.
Note:
Fan modules and M.2 flash SSDs are hot-pluggable and do not require AC
power cables to be disconnected from the server power supplies.
2. If the release button latch is in the locked position, use a Torx T15 screwdriver to turn the
release button latch clockwise to the unlocked position.
3. Unlatch the top cover [1].
Lift up on the release button on top of the server cover. Lifting the release button slides
the server cover toward the rear of the chassis for easy removal.
Chapter 2
Preparing the Server for Component Replacement
2-19
