Overview of System Status Indicators and
LEDs
Learn about various Oracle Database Appliance model indicators and LEDs.
Note:
For information about system features and racking, refer to the Oracle Database
Appliance Owner's Guide. For information about cabling, Oracle ILOM initial setup,
and appliance software setup, refer to the Oracle Database Appliance Deployment
and User's Guide for your model.
• Oracle Database Appliance X10-S/X10-L Status Indicators
Learn about Oracle Database Appliance X10-S/X10-L status indicators.
• Oracle Database Appliance X10-HA Status Indicators
Learn about Oracle Database Appliance X10-HA status indicators.
Oracle Database Appliance X10-S/X10-L Status Indicators
Learn about Oracle Database Appliance X10-S/X10-L status indicators.
• Oracle Database Appliance X10-S/X10-L Server Status Indicators
See a description of the front and back status indicators for the Oracle Database
Appliance X10-S/X10-L.
Oracle Database Appliance X10-S/X10-L Server Status Indicators
See a description of the front and back status indicators for the Oracle Database Appliance
X10-S/X10-L.
• Server Front Panel Status Indicators
See a listing of the various font panel status indicators for the Oracle Database Appliance
X10-S/X10-L.
• Server Back Panel Status Indicators
See a listing of the various back panel status indicators for the Oracle Database
Appliance X10-S/X10-L.
Server Front Panel Status Indicators
See a listing of the various font panel status indicators for the Oracle Database Appliance
X10-S/X10-L.
The following figure shows the Oracle Database Appliance X10-S/X10-L server front panel
includes indicators for the system and storage drives.
