Note:
Only authorized Oracle Service personnel can service FRU components.
FRU (Service Level) Description Replacement
Instructions
Processor and
heatsink (Cold
service)
Processor that carries out the instructions of
the system.
Servicing Processors
Fan tray (Cold service) Houses the fan modules. Servicing the Fan Tray
Disk backplane (Cold
service)
Provides power and communications
connectors for storage drives.
Servicing the Disk
Backplane
Front LED indicator
module (Cold service)
Contains the push-button circuitry and LEDs
that are displayed on the front panel.
Servicing the Front
LED Indicator Module
PCIe slot Flyover
cable (Cold service)
Supports PCIe slots 6 and 7 in the system. Servicing the PCIe
Slot Flyover Cable
(FRU)
Motherboard
assembly (Cold
service)
Provides connectors for the DIMMs,
processors, PCIe risers, and other
components.
Servicing the
Motherboard
Assembly
Related Topics
•
•
Safety Precautions
For your protection, observe the following safety precautions when setting up your
equipment:
• Follow all standard cautions, warnings, and instructions marked on the equipment
and described in the Oracle Server Safety and Compliance Guide and Important
Safety Information for Oracle's Hardware Systems.
• Ensure that the voltage and frequency of your power source match the voltage
and frequency that appear on the equipment electrical rating label.
• Follow the electrostatic discharge safety practices as described in Electrostatic
Discharge Safety.
• Disconnect both power supply cords (if necessary) before servicing components.
Note:
Power cords must be disconnected when servicing components that
require cold service.
Chapter 2
Safety Precautions
2-4
