Callout Indicator/LED: Color State Meaning
5 Top fan: amber Indicates that one (or more) of
the internal fan modules has
failed.
• Off - Indicates steady
state; no service is
required.
• On - Indicates service
required; service the
failed fan module.
6 Rear PS: amber Indicates that one (or more) of
the power supplies has failed.
• Off - Indicates steady
state; no service is
required.
• On - Indicates service
required; service the
failed power supply.
7 Over temperature warning:
amber
• Off - Normal operation; no
service is required.
• On - The system is
experiencing an over
temperature warning
condition.
This is a warning indication,
not a fatal over temperature.
Failure to correct this condition
might result in the system
overheating and shutting down
unexpectedly.
8 Service processor (SP): green • Off - The service
processor (SP) is not
running.
• On - The SP is fully
operational.
• Slow blink - SP is booting.
9 DO NOT SERVICE: white Indicates that the system is
not ready to service.
• Off - Normal operation.
• On - The system is not
ready for service.
The DO NOT SERVICE
indicator is application
specific. This indicator is only
illuminated on demand by the
Host application.
Server Node Back Panel Status Indicators
See a listing of the various back panel status indicators for the Oracle Database Appliance
X10-HA server node.
The following figure shows the Oracle Database Appliance X10-HA server node back panel
and includes indicators for the system, power supplies and network ports.
Chapter 1
Oracle Database Appliance X10-HA Status Indicators
1-9
