Callout Description
13 Air baffle
14 System RTC battery
15 Two power supplies (PS0, PS1)
16 (Optional) Nine half-height half-length PCIe cards
PCIe slots 1 through 4 are nonfunctional in single-processor systems.
Customer-Replaceable Units
The following table lists the customer-replaceable units (CRUs) in the server, describes
whether they can be serviced hot (with appliance power on) or cold (with appliance power off)
and directs you to the replacement instructions.
CRU (Service Level) Description Replacement
Instructions
Server battery (Cold
service)
Lithium coin-cell battery that powers the CMOS
BIOS and real-time clock.
Servicing the Battery
Server DIMMs (Cold
service)
Add or replace memory modules in the system. Servicing the DIMMs
Server storage drives
(Hot service)
Storage drive configurations can be comprised of
both hard disk drives (HDDs), solid state disk
drives (SSDs), or NVMe drives.
Servicing Server
Storage Drives
Server internal M.2 flash
SSDs (Cold service)
Supports up to two internal M.2 flash SSDs. Servicing the Internal
M.2 Flash SSDs
Server fan modules (Hot
service)
Four fan modules for cooling the server
components.
Servicing Fan Modules
Server PCIe cards (Cold
service)
Optional add-on cards that can expand the
functionality of the server.
Servicing PCIe Cards
Server power supply
units (Hot service)
Two fully redundant AC-powered power supplies. Servicing Power
Supplies
Storage Shelf
components (Hot
service)
Storage shelf SSDs, power supplies and IO
modules.
Oracle Database
Appliance X10-HA
Storage Shelf Hot
Pluggable Components
Related Topics
• Field-Replaceable Units
• Illustrated Parts Breakdown
Identify major components of Oracle Database Appliance X10 server.
Field-Replaceable Units
The following table lists the field-replaceable units (FRUs) in the server and directs you to the
replacement instructions.
Chapter 2
Servicing System Components
2-3
