6. Reinstall PCIe cards.

See Install a Half Height PCIe Card.

7. Reinstall the fan tray.

See Install the Fan Tray.

8. Reinstall the fan modules.

See Install a Fan Module.

9. Reinstall the air baffle.

See Install the Air Baffle.

10. Reinstall the power supplies.

See Install a Power Supply.

Chapter 5

Servicing the Motherboard Assembly (FRU)

5-51

Table of Contents3
Audience7
Documentation Accessibility7
Related Documents7
Conventions8
Overview of System Status Indicators and Leds9
Oracle Database Appliance X10-S/X10-L Status Indicators9
Oracle Database Appliance X10-S/X10-L Server Status Indicators9
Server Front Panel Status Indicators9
Server Back Panel Status Indicators13
Oracle Database Appliance X10-HA Status Indicators14
Oracle Database Appliance X10-HA Server Node Status Indicators15
Server Node Front Panel Status Indicators15
Server Node Back Panel Status Indicators17
Oracle Database Appliance X10-HA Storage Shelf Indicators20
Storage Shelf Front Panel Status Indicators20
Storage Shelf Back Panel Status Indicators22
Preparing Oracle Database Appliance for Service24
Servicing System Components24
Illustrated Parts Breakdown24
Customer-Replaceable Units26
Field-Replaceable Units26
Safety Precautions27
Safety Symbols28
Electrostatic Discharge Safety28
FRU Key Identity Properties (KIP) Automated Update29
Required Service Tools29
Preparing the Server for Component Replacement30
Powering down the Server30
Power down the Server Gracefully Using Oracle ILOM CLI31
Power down the Server Gracefully Using Oracle ILOM Web Interface32
Power down the Server Gracefully Using the On/Standby Button32
Power down the Server for Immediate Shutdown Using Oracle ILOM CLI33
Power down the Server for Immediate Shutdown Using Oracle ILOM Web Interface33
Power down the Server for Immediate Shutdown Using the On/Standby Button34
Disconnect Cables from the Server35
Stabilize the Rack35
Extend the Server to the Maintenance Position36
Remove the Cable Management Arm37
Remove the Server from the Rack40
Take Antistatic Measures41
Remove the Server Top Cover42
Remove the Air Baffle43
Servicing Crus that Do Not Require System Power off45
Oracle Database Appliance X10 Server Hot-Pluggable Components45
Servicing Nvme Storage Drives (CRU)46
Replacing an Nvme Storage Drive46
Adding Nvme Expansion Storage48
Servicing Fan Modules (CRU)49
Remove a Fan Module50
Install a Fan Module51
Servicing Power Supply Modules (CRU)52
Remove a Power Supply52
Install a Power Supply54
Oracle Database Appliance X10-HA Storage Shelf Hot Pluggable Components55
Adding Optional Storage Shelf Drives (CRU)56
Replace a Storage Shelf HDD or SSD (CRU)60
Replace a Storage Shelf Power Supply (CRU)61
Replace a Storage Shelf I/O Module (CRU)64
Servicing Crus that Require System Power off66
Servicing Internal M.2 Flash Ssds (CRU)66
Identify and Remove an M.2 Flash SSD67
Install an M.2 Flash SSD69
Remove a Flash Riser Board70
Install a Flash Riser Board72
Servicing Dimms (CRU)73
DIMM and Processor Physical Layout74
DIMM Population Scenarios75
DIMM Population Rules75
Populating Dimms for Optimal System Performance76
Using the Server Fault Remind Button77
Identify and Remove a DIMM78
Install a DIMM79
Servicing Pcie Cards (CRU)80
Pcie Slot Locations81
Adding Optional Pcie Cards (CRU)81
Remove a Half Height Pcie Card83
Install a Half Height Pcie Card85
Servicing the Battery (CRU)87
Remove the Battery87
Install the Battery90
Servicing Frus93
Servicing Processors (FRU)93
Processor Overview94
Identify and Remove a Processor95
Install a Processor104
Servicing the Fan Tray (FRU)111
Remove the Fan Tray111
Install the Fan Tray113
Servicing the Disk Backplane (FRU)114
Remove the 4-Drive Backplane115
Install the 4-Drive Backplane118
Remove a Disk Backplane Cable122
Install a Disk Backplane Cable124
Servicing the Front LED Indicator Module (FRU)125
Remove the Front LED Indicator Module126
Install the Front LED Indicator Module128
Servicing the Pcie Slot Flyover Cable (FRU)129
Remove the Pcie Flyover Cable129
Install the Pcie Flyover Cable130
Servicing the Motherboard Assembly (FRU)131
Remove the Motherboard Assembly132
Install the Motherboard Assembly141
Component Fault Management144
Returning Oracle Database Appliance to Operation145
Install the Air Baffle145
Install the Server Top Cover146
Remove Antistatic Measures146
Reinstall the Server into the Rack147
Return the Server to the Normal Rack Position148
Install the Cable Management Arm (Optional)149
Powering on Oracle Database Appliance157
Server Node Diagnostic Tools and Resetting the Service Processor159
Server Node Diagnostic Tools159
Manually Resetting a Server's Service Processor160
Server Basic Input/Output System (BIOS)162
Accessing the BIOS Setup Utility162
BIOS Setup Utility Menus162
BIOS Key Mappings163
Access BIOS Setup Utility Menus163
Navigate BIOS Setup Utility Menus164
Using UEFI BIOS165
Configuration Utilities for Add-In Cards165
Configure and Manage BIOS Using Oracle ILOM165
UEFI Secure Boot165
