Oracle Database Appliance X10 User Manual

Callout Indicator/LED: Color State Meaning
1 Locate: white • Off - Normal operation.
• Fast blink - This LED blinks
to help locate the system.
Operators can turn this
indicator on and off remotely
using Oracle ILOM.
• Pressing this button toggles
the fast blink on or off.
2 Service Required: amber • Off - Normal operation.
• Steady on - A fault is
present in the storage shelf.
3 OK: green • Off - The storage shelf is
unplugged or turned off.
• On - The storage shelf is
powered on and operating
normally.
4 Power Supply fault indicator:
amber
• Off - Normal operation.
• On - Indicates a fault with a
power supply. View the
LEDs at the back of the
storage shelf to determine
which power supply has the
fault.
5 SAS I/O Module fault indicator:
amber
• Off - Normal operation.
• On - Indicates a fault with a
SAS I/O module. View the
LEDs at the back of the
storage shelf to determine
which module has the fault.
6 Ready-to-Remove: blue • Off - The storage drive has
not been prepared for
removal.
• On - The storage drive can
be safely removed during a
hot-plug operation.
7 Drive Service Required: amber • Off - Normal operation.
• Steady on - A fault is
present in the disk drive.
8 Power/Activity: green • Off - The drive is powered
off or the installed drive is
not recognized by the
system.
• On - The drive is installed
and recognized by the
system but there is no drive
activity.
• Blink - The LED blinks
randomly in response to
data being written to or read
from the drive.
Chapter 1
Oracle Database Appliance X10-HA Status Indicators
1-13

Oracle Database Appliance X10 Specifications

General

Brand	Oracle
Model	Database Appliance X10
Category	Storage
Language	English
