Oracle Database Appliance X10 User Manual

Callout Indicator/LED: Color State Meaning
7 Locate: white • Off - Normal operation.
• Fast blink - This LED
blinks to help locate the
system. Operators can
turn this indicator on and
off remotely using Oracle
ILOM.
• Pressing this button
toggles the fast blink on or
off.
8 Service Required: amber • Off - Normal operation.
• Steady on - A fault is
present in the storage
shelf.
9 OK: green • Off - The storage shelf is
unplugged or turned off.
• On - The storage shelf is
powered on and operating
normally.
10 SAS I/O Module Ready-to-
Remove: blue
• Off - The I/O module has
not been prepared for
removal.
• On - The I/O module can
be safely removed during
a hot-plug operation.
11 SAS I/O Module Service
Required indicator: amber
• Off - Normal operation.
• Steady on - A fault is
present in the SAS I/O
module.
12 SAS I/O Module OK: green • Off - The I/O module is
unplugged or turned off.
• On - The I/O module is
powered on and operating
normally.
13 Host SAS port Service
Required indicator: amber
• Off - Normal operation.
• Steady on - A fault is
present with the port or
connection.
14 Host SAS port activity
indicator: green
• Off - No link activity.
• Random blinking -
Indicates host SAS link
activity.
Chapter 1
Oracle Database Appliance X10-HA Status Indicators
1-15
