range Pi User Manual Copyright reserved by Shenzhen Xunlong Software Co., Ltd

228

2) Then find Chinese (China) option

3) Then use the left mouse button to select Chinese (China) and hold it down, and then

drag it up to the beginning. The display is shown below

：
