range Pi User Manual Copyright reserved by Shenzhen Xunlong Software Co., Ltd

229

Note that this step is not easy to drag, please try more patiently

。

4) Then select the Apply System-Wide to apply the Chinese settings to the entire system

5) Then set the Keyboard input method system to fcitx
