– 101 –
Chapter 5 Basic Operations — Project management
5
Select [OK].
f The project le is loaded.
Editing data in a memory card or the storage module
Delete data saved in a memory card or the Storage Module AV‑HS60D1 (optional), or change le names.
1
Select the <PRJ> button → [PROJECT] → [SD/SSD] tab.
2
Select an item in [Misc] in the [SD]/[SSD] column.
f The [Misc] screen is displayed.
[Protect]*
1
*
2
Select a le icon and set this item to [On] to protect the relevant le. The protected le is not deleted even when [Delete]
is selected.
[Rename]*
1
Select [Rename] after selecting a le icon to change the le name using the on‑screen keyboard.
[Delete] Select [Delete] after selecting a le icon to delete the register memory. It cannot be deleted if [Protect] is set to [On].
[Sort] Sorts the le icon view in ascending or descending order by le number, le name, or date.
[View] Fixed to icon display.
[Close] Closes the [Misc] screen.
*1 This function will be available in V2.00.00 or higher.
*2 Displayed only on the [Misc] screen in the [SSD] column.
Saving and loading data in/from the local computer
Project les can be saved and loaded in/from the internal storage of the local computer connected to the <LAN> terminal of the Main Frame
AV-HS60U1/AV-HS60U2.
@@
NOTE
t This function will be available in V2.00.00 or higher.
Saving data in the local computer
1
Select the <PRJ> button → [PROJECT] → [Project] tab.
2
Select an item in [Save] in the [Local] column.
f The le operation screen of the computer opens, and the project le can be saved in the internal storage of the computer.
f The save target is xed to all items.
Loading data from the local computer
1
Select the <PRJ> button → [PROJECT] → [Project] tab.
2
Select an item in [Load] in the [Local] column.
f The le operation screen of the computer opens, and the project le can be loaded from the internal storage of the computer.
f The load target is xed to all items.
To Next Page
