Chapter 10 Specications — Specications
Specications
Main Frame AV‑HS60U1/AV‑HS60U2
Power supply
AC 100 V to 240 V, 50 Hz/60 Hz
Power consumption
110 W
AV-HS60U2 supports redundant power supply.
indicates safety information.
Video terminal
<SDI IN 1> to <SDI IN 32> terminals 32 lines
f Connectors: BNC×32
f <SDI IN 27>, <SDI IN 28>, <SDI IN 31>, and <SDI IN 32> terminals are equipped with up-converters.
f <SDI IN 25> to <SDI IN 32> terminals are equipped with color correctors.
HD-SDI HD serial digital, SMPTE292M (BTA S-004) standard compliant
f 0.8 V [p-p] ±10% (75 Ω)
f Automatic equalizer 100 m (328 ft) (when 1.5 Gbps/5C-FB cable is used)
SD-SDI SD serial digital, SMPTE259M standard compliant
f 0.8 V [p-p] ±10% (75 Ω)
f Automatic equalizer 200 m (656 ft) (when 5C-2V cable is used)
<DVI-D IN1>/<DVI-D IN2> terminals 2 lines
Digital RGB: XGA (1024×768), WXGA (1280×768), SXGA (1280×1024), WSXGA+ (1680×1050), UXGA (1600×1200),
WUXGA (1920×1200)
Vertical frequency: 60 Hz
Video format inputs: 1080/50p, 1080/59.94p, 1080/50i, 1080/59.94i, 720/50p, 720/59.94p
f Connectors: DVI-D×2
f The terminals do not support HDCP.
f The DVI-I connector cable cannot be used.
f For the DVI-D connector cable, use a cable with a length of up to 5 m (16.4 ft).
<SDI OUT 1> to <SDI OUT 16>
terminals
16 lines (2 distribute outputs per line)
f Connectors: BNC×32
f ME1PGM, ME1PVW, ME1CLN, ME1KEYPVW, ME2PGM, ME2PVW, ME2CLN, ME2KEYPVW, DSKPGM1, DSKPGM2,
DSKPVW1, DSKPVW2, DSK1CLN, DSK2CLN, DSK3CLN, DSK4CLN, SEL KEYPVW, MV1 to MV4, and AUX1 to
AUX16 can be assigned.
HD-SDI HD serial digital, SMPTE292M (BTA S-004) standard compliant
f Output level: 0.8 V [p-p] ±10%
f Rise time: Less than 270 ps (HD)
f Fall time: Less than 270 ps (HD)
f Difference between rise time and fall time: 100 ps or less (HD)
f Alignment jitter: 0.2 UI (130 ps) or less (HD)
f Timing jitter: 1.0 UI or less (HD)
f Eye aperture ratio: 90% or more
f DC offset: 0±0.5 V
SD-SDI SD serial digital, SMPTE259M standard compliant
f Output level: 0.8 V [p-p] ±10%
f Rise time: 1.5 ns or less
f Fall time: 1.5 ns or less
f Difference between rise time and fall time: 0.5 ns or less
f Jitter: 0.2 UI or less
Signal formats SD 480/59.94i, 576/50i
HD 1080/59.94i, 1080/50i, 720/59.94p*, 720/50p*, 1080/24PsF*, 1080/23.98PsF*
Signal processing Y:P
B
:P
R
4:2:2 10 bits
R:G:B 4:4:4 8 bits
ME number 2ME
* 720/59.94p, 720/50p, 1080/24PsF, and 1080/23.98PsF will be available in V2.00.00 or higher.
Synchronous terminal
<REF> terminal In Genlock mode: Black burst or Tri-level Sync input signals (with loop-through)
f If the loop-through output is not used, provide a 75 Ω termination.
In internal sync mode: Black burst output signal ×2
f Connector: BNC
f Same eld frequencies as those of the system formats supported
f In the 1080/24PsF and 1080/23.98PsF formats, only Genlock mode supported
f In the 1080/23.98PsF format, black burst signals with 10 Field ID (SMPTE318M standard compliant) or Tri-level Sync
signals supported
