Chapter 5 Basic Operations — Internal color signals
Internal color signals
The unit supports two lines of internal color signals.
Setting the color background
Set the color of the color background to be used by the bus.
The color can be set by setting the hue (Hue), saturation (Sat), and luminance (Lum), or by recalling the preset eight colors. The recalled colors can also
be adjusted using [Hue], [Sat], and [Lum].
Adjusting the colors
1
Select the <DSK MISC> button → [CBGD] → [CBGD1]/[CBGD2] tab.
2
Adjust the color.
f Set [Hue], [Sat], [Lum], or [Color Palette] in the [Main Color]/[Sub Color] column.
Setting the gradation
Set the gradation effect for color backgrounds.
Selecting the gradation effects and setting the colors
1
Select the <DSK MISC> button → [CBGD] → [CBGD1]/[CBGD2] tab.
2
Select an item in [Wash] in the [Wash] column.
[On] Adds the gradation effect.
[Off] Does not add the gradation effect.
3
Select an item in [Color Type] in the [Wash] column.
[Dual] Adds the two color gradation effect set in the [Main Color] and [Sub Color] columns.
[Rainbow] Adds the rainbow color gradation effect.
4
Adjust the color.
f When [Dual] is selected, set [Hue], [Sat], [Lum], or [Color Palette] in the [Sub Color] column.
f When [Rainbow] is selected, set [Rainbow Sat] and [Rainbow Lum] in the [Wash] column.
Adjusting the gradation waveforms
1
Select the <DSK MISC> button → [CBGD] → [CBGD1]/[CBGD2] tab.
2
Select an item in [Pattern] in the [Wave] column.
[Sine] Selects sine waves.
[Saw] Selects sawtooth waves.
3
Set [Cycle], [Phase], and [Angle] in the [Wave] column.
[Cycle] Selects the gradation cycle.
[Phase] Selects the gradation phase.
[Angle] Selects the gradation angle.
Setting the gradation movement
1
Select the <DSK MISC> button → [CBGD] → [CBGD1]/[CBGD2] tab.
2
Select an item in [Type] in the [Move] column.
[Off] Sets no movement.
[Roll] Scrolls the gradations.
[Rotation] Rotates the gradations.
3
Set [Speed] in the [Move] column.
f Set the speed of the gradation movement.
