Chapter 5 Basic Operations — Background transition
Background transition
Selecting a bus
Select sources to be used for background transitions.
1
Press the crosspoint buttons.
f Depending on the operating status, the buttons pressed will light in one of three color patterns.
Type Color when lit* Description
High tally [Red] Lights when the selected source is included in the on-air output.
Low tally [Yellow]
Lights when the selected source is not included in the on-air output but
included in the program output.
Preset tally [Green]
Lights when the selected source is included in neither the on-air output
nor the program output.
* Indicates the default colors. To change the colors, select the <SYS> button on the top menu → [CTRL PANEL] → [Button Color] tab → [Select Button]
column.
f The color when lit for the buttons not selected can also be set by source or by block. (page 135)
Selecting a bus using the SHIFT function
The SHIFT function is to switch pages of the crosspoint buttons with the <2nd PAGE>/<3rd PAGE> button.
There are two ways to perform the SHIFT function.
All SHIFT
Use the <2nd PAGE>/<3rd PAGE> button to switch all pages of buses included in the corresponding ME at once.
(page 22)
Single SHIFT
Assign the <2nd PAGE>/<3rd PAGE> button to the crosspoint buttons to switch pages. (page 118)
Using the assigned button, only the pages of individual bas can be switched.
The <2nd PAGE>/<3rd PAGE> buttons are available in two modes. The setting can be changed using the menu. (page 121)
[Normal] The buttons are turned on only while they are pressed.
[Page Lock] The buttons are turned on and off each time they are pressed.
Selecting the bus mode
Set the bus operation mode. (page 121)
1
Select the <CONF> button → [OPERATE] → [Transition] tab.
2
Select an item in [Bus Mode] in the [Bus Mode] column.
[A/B]
When the fader lever is at side A, the signals selected on the A bus are used as the source of the PGM bus.
When the fader lever is at side B, the signals selected on the B bus are used as the source of the PGM bus.
[PGM‑A/PST‑B]
Using a ip‑op system, the signals selected on the A bus are always used as the source of the PGM bus, and the
signals selected on the B bus are always used as the source of the PST bus.
[PGM‑B/PST‑A]
Using a ip‑op system, the signals selected on the B bus are always used as the source of the PGM bus, and the
signals selected on the A bus are always used as the source of the PST bus.
Transition operations
Execute transitions using the transition area on the Control Panel AV-HS60C1/AV-HS60C2.
1
Press the <BKGD> button.
f Select the transition target.
Multiple targets can be selected by pressing the <KEY1>/<KEY2>/<KEY3>/<KEY4> buttons simultaneously.
2
Select the transition type.
f Use the transition type selection buttons. (page 23)
3
Execute the transition using the fader lever or the transition execution button.
Manual transition Move the fader lever to execute the transition.
Auto transition Press the <AUTO> button to execute the transition automatically.
Cut transition Press the <CUT> button to execute the transition instantaneously.
f The bus tallies on the right of the PGM/A bus crosspoint buttons and the PST/B bus crosspoint buttons indicate the output status of the program
bus.
Lighting color Description
Red Lights when the relevant bus is included in the on-air output.
Amber Lights when the relevant bus is not included in the on-air output but included in the program output.
Off Lights when the relevant bus is included in neither the on-air output nor the program output.
