Chapter 5 Basic Operations — DSK (Downstream key)
DSK (Downstream key)
Combine characters or other images with the background image of ME1PGM or ME2PGM output.
To select ME1PGM or ME2PGM output, use the <SYS> button on the top menu → [MAIN FRAME] → [DSK] → [Assign] in the [Cong] column.
(page 133)
Selecting the DSK type
Set the key type on the Menu Panel AV-HS60C3.
1
Select the <DSK MISC> button → [DSK1] to [DSK4] → [Setting] tab.
2
Select an item in [Type] in the [DSK] column.
f Select the method to generate key signals. The selection status is stored for each source.
[Lum]
(luminance key/self key)
Creates key signals from luminance components or luminance and chrome components of key ll signals.
f Since the luminance key is operated as a self key, the key ll signals are used as the key source signals.
The key signals do not change even when the key source signals are switched.
[Linear]
(linear key)
Creates key signals from luminance components of key source signals. It is used when the key source signal and key ll
signal are different.
f Use source with a black background and white characters or shape to be combined by the key as the key source
signal. Source which is not black and white may not be combined clearly. Source with white background and black
characters can be used by inverting the keys with the key invert function.
3
Select an item in [Lum Key] in the [DSK] column.
[Chroma Off] Generates the key signals only from the luminance components.
[Chroma On]
Generates the key signals considering the chrome components in addition to the luminance components. This item is set
when a low luminance component color is used for key signals such as when cutting blue characters.
4
Select an item in [Clean Key] in the [DSK] column.
[Off] Cuts key ll with a key signal.
[On]
Does not cut key ll with a key signal. The part of key ll not cut out with the key signal is superimposed on the
background image.
Selecting the source type
1
Select the <DSK MISC> button → [DSK1] to [DSK4] → [Setting] tab.
2
Select an item in [Source Type] in the [DSK] column.
f Select the mode to link selection of key source signal with key ll selection.
[Self Key] Uses the source selected in the key ll bus column as the key source signal.
[External Key] Always uses an external key. The source signal for ll is set using [Fill] in the [DSK] column.
Selecting the ll type
Select the ll type.
1
Select the <DSK MISC> button → [DSK1] to [DSK4] → [Setting] tab.
2
Select an item in [Fill] in the [DSK] column.
[Bus] Uses the bus signal for the key ll signal.
[Matte] Uses the internal ll matte for the key ll signal. The color set in the [Fill Matte] column is used for the ll matte color.
Setting the matte color
Set the ll matte color.
1
Select the <DSK MISC> button → [DSK1] to [DSK4] → [Setting] tab.
2
Adjust the color.
f Set [Hue], [Sat], [Lum], or [Color Palette] in the [Fill Matte] column.
Selecting the DSK source
For details on selecting DSK sources, refer to “Selecting the key source” (page 52).
