– 78 –
Chapter 5 Basic Operations — Switching the AUX output
Switching the AUX output
Selecting the AUX output sources
Display the AUX output image on the monitor using the output settings or the settings of the MultiView display.
Press one of the KEY bus selector buttons <AUX 1/2> to <AUX 15/16> of ME1 to select odd number buses among the AUX1 bus to the AUX15 bus.
T
o select even number buses among the
AUX2 bus to the
AUX16 bus, press <AUX 1/2> to <AUX 15/16> buttons while holding down the <BUS SHFT>
button.
The source selected using the KEY bus cross point buttons is output.
r Signals that can be selected on the AUX bus
Signal name Description of signal
SDI IN1 - SDI IN32 SDI input signals 1 to 32
DVI IN1, DVI IN2 DVI-D input signals
Still 1V, Still 2V, Still 3V, Still 4V Video memory (still image) 1 to 4 videos
Still 1K, Still 2K, Still 3K, Still 4K Video memory (still image) 1 to 4 keys
Clip 1V, Clip 2V, Clip 3V, Clip 4V Video memory (moving image) 1 to 4 videos
Clip 1K, Clip 2K, Clip 3K, Clip 4K Video memory (moving image) 1 to 4 keys
CBGD1, CBGD2 Color background 1, 2
CBAR Color bar
Black Black image
ME1PGM, ME2PGM Program video signal
ME1PVW, ME2PVW Preview video signal
ME1CLN, ME2CLN Clean signal
ME1KEYPVW, ME2KEYPVW Key preview video signal
DSKPGM1, DSKPGM2 Program video signal
DSKPVW1, DSKPVW2 DSK preview video signal
DSK1CLN - DSK4CLN Clean signal
SEL KEYPVW Selected key preview video signal
MV1 - MV4 MultiView display output signal
@@
NOTE
t When the AUX bus image for which the MultiView display output has been selected is displayed on the sub-screen of the MultiView display, the
images are looped as if two mirrors were facing each other.
Transitions of AUX1 to AUX4 buses
AUX1 to AUX4 buses can perform MIX transitions.
For details, refer to “AUX1 to AUX4 bus transitions” (page 122).
Linking AUX buses
Set the <CONF> button on the top menu → [SOURCE LINK] → [AUX Bus Link] tab to link two AUX buses.
For details, refer to “Linking the AUX bus” (page 120).
