Panasonic AV-HS6000 - Setting Multiview Displays; Setting a Tally; Setting the State Replicated When Power Is on; Setting Date and Time

– 44 –
Chapter 4 Preparations — Various settings
[Down Converter] tab Makes the settings for down-converters built into the <SDI OUT 14>/<SDI OUT 16> terminals.
2
Select the <IN OUT> button → [C/C OUT] → [SDI OUT 13] to [SDI OUT 16] tabs, and make the color corrector settings.
f This function will be available in V2.00.00 or higher.
f Make the settings for color correctors built into the <SDI OUT 13> to <SDI OUT 16> terminals.
f For details on the settings output from the ME/DSK block such as ME1CLN and ME2CLN, refer to “Setting the ME output and DSK output”
(page 132).
Setting MultiView displays
If the output signal is set to MV1 to MV4, multiple images can be simultaneously displayed on a maximum of 16 split screens.
f For details, refer to “Setting MultiView displays” (page 114).
1
Select the <MV> button → [MV1‑4] → [MV1] to [MV4] tabs.
2
In the [Pattern] column, make the settings for the split pattern of the MultiView display.
f When [Assign] is selected, the source settings screen will be displayed on a sub-screen.
3
In the [MV Frame]/[Tally Box]/[Tally Label L]/[Tally Label R]/[Display] column, set the information displayed on the sub‑screen.
f [Tally Label L]/[Tally Label R] will be available in V2.00.00 or higher.
Setting a tally
Setting reference outputs
For details on the tally group settings, refer to “Setting a tally” (page 136).
1
Select the <SYS> button → [PERIPHERAL] → [Tally] tab.
2
Select an item in [Target A], [+Target B], [+Target C], or [+Target D] in the [Tally Group1‑1] column.
f Select up to 4 reference outputs to be used for the on-air tally.
3
Select an item in [Target A], [+Target B], [+Target C], or [+Target D] in the [Tally Group2‑1] to [Tally Group4‑1] columns.
f Besides [Tally Group1-1], additional 3 tally groups can be set. When [Color] is selected, colors to be used for the tally in the MultiView display can
also be set.
Setting the parallel tally
1
Select the <SYS> button → [PERIPHERAL] → [GPI IN]/[GPI OUT] tab, and make the following settings.
[GPI IN] tab Assigns Tally G1 DSBL through Tally G4 DSBL to externally control enabling/disabling of each tally group.
[GPI OUT] tab Assigns source tally outputs by tally group.
Setting the state replicated when power is on
Set the status replicated when the power is turned on.
f For details on the settings, refer to “Startup settings/initialization” (page 140).
1
Select the <SYS> button → [MAINTENANCE] → [Boot] tab.
2
Make the following settings in the [Boot Select]/[Project Data] column.
[Boot Select] column Selects the setting data to be used at the startup from resume data and project data.
[Project Data] column Species project le to be used at the startup.
Setting date and time
Set the date and time to be used as a timestamp when saving les to the memory card or the Storage Module AV‑HS60D1 (optional). It can also be
displayed on the split screen of the MultiView display.
1
Select the <SYS> button → [MAINTENANCE] → [Misc] tab.
2
Set the date and time in the [Date]/[Time]/[LTC] columns.
[Date] column Sets the year, month, and date in [Year], [Month], and [Date].
[Time] column Sets the hour, minute, and second in [Hour], [Minute], and [Second].
[LTC] column Displays the information input to the <LTC IN> terminal and reects it in the [Time] column.
