Panasonic AV-HS6000 - MV> Button (Top Menu); PLUG IN> Button (Top Menu)

– 166 –
Chapter 11 Appendix — Setting menu table
[Status] tab
Column Item Detailed setting Default
[SDI IN 1] - [SDI
IN 32]
[Format] ― ―
[Audio] ― ―
[Up Converter] tab
Column Item Detailed setting Default
[SDI IN 27],
[SDI IN 28],
[SDI IN 31],
[SDI IN 32]
[Scale] [Squeeze], [Edge Crop],
[Letter Box]
[Squeeze]
[Motion Detect] [1] - [5] [3]
[Sharp] [1] - [5] [3]
[Size] [100] - [110] [100]
[Edge Crop
Pos.]
[Center], [Right], [Left] [Center]
[DVI IN] (function menu)
[Frame Buffer] tab
Column Item Detailed setting Default
[DVI IN 1], [DVI
IN 2]
[Scale] [Full], [Fit-V], [Fit-H] [Full]
[Freeze mode] [Frame], [Field] [Frame]
[Freeze] [Off], [On] [Off]
[Status] tab
Column Item Detailed setting Default
[DVI IN 1], [DVI
IN 2]
[Size] ― ―
[Dot Clock] ― ―
[H-Frequency] ― ―
[V-Frequency] ― ―
[SDI OUT] (function menu)
[Assign] tab
The assignment setting screen is displayed.
[Down Converter] tab
Column Item Detailed setting Default
[SDI OUT 14],
[SDI OUT 16]
[Limit] [Off], [108%], [104%],
[100%]
[Off]
[Enable] [Off], [On] [Off]
[Scale] [Squeeze], [Edge Crop],
[Letter Box]
[Squeeze]
[Delay] [90H] ([75H]), [1F] [90H]
([75H])
[Sharp] [1] - [5] [3]
[C/C IN 25‑30], [C/C IN 31‑32] (function menu)
This function will be available in V2.00.00 or higher.
[C/C OUT] (function menu)
This function will be available in V2.00.00 or higher.
<MV> button (top menu)
[MV1‑4] (function menu)
[MV1]/[MV2]/[MV3]/[MV4] tab
Column Item Detailed setting Default
[Pattern] [Split] [4Split], [5-aSplit],
[5-bSplit], [6-aSplit],
[6-bSplit], [9Split],
[10-aSplit], [10-bSplit],
[16Split]
[10-aSplit]
― ― ―
― ― ―
― ― ―
[Assign] (Assignment setting
screen)
―
Column Item Detailed setting Default
[MV Frame] [Frame] [LUM 0%], [LUM 25%],
[LUM 50%], [LUM 75%],
[LUM 100%], [Off]
[LUM 75%]
[Character] [LUM 0%], [LUM 25%],
[LUM 50%], [LUM 75%],
[LUM 100%], [Off]
[LUM 75%]
[Label] [Off], [On] [On]
[Tally Box] [Tally Group1] -
[Tally Group4]
[Off], [On] [Off]
[Display] [Level Meter] [Off], [On] [Off]
[Input Status] [Off], [On] [On]
[Marker] [Off], [4:3], [16:9] [Off]
[Marker Size] [80%] - [100%] [95%]
<PLUG IN> button (top menu)
This function will be available in V2.00.00 or higher.
