Chapter 10 Specications — Dimensions
Dimensions of the Control Panel AV‑HS60C1/AV‑HS60C2
Unit: mm (inch)
153.4 (6-1/32)
8.2 (5/16)
(33 (1-5/16))
250 (9-27/32)
267 (10-1/2)
132 (5-3/16)
51 (2)
56 (2-7/32)
8.5 (11/32)
10 (13/32)
50 (1-31/32)
(18 (23/32))
19.5 (25/32)
980 (38-19/32)
702 (27-5/8)
951 (37-7/16)
18 (23/32)
69.5 (2-3/4)
11.6 (15/32)
