Setting the operation mode
Setting the operation mode for the crosspoint buttons
Selecting a bus using the SHIFT function
The SHIFT function is used to assign four sources to one crosspoint button (the KEY, PGM/A, or PST/B crosspoint button) and change pages using the
<2nd PAGE>/<3rd PAGE> buttons on the right of the source name display panel.
There are two operation methods for the SHIFT function:
All SHIFT
Use the <2nd PAGE>/<3rd PAGE> buttons to change all source pages for the crosspoint buttons included in the
corresponding ME at once.
Single SHIFT
Assigns the <2nd PAGE>/<3rd PAGE> buttons to the KEY bus crosspoint buttons in the menu.
Use the assigned button to change the source page of the crosspoint buttons included in the corresponding ME on a bus
basis. In this case, the <2nd PAGE>/<3rd PAGE> buttons on the right of the source name display panel can be used to
switch the source name displays.
The <2nd PAGE>/<3rd PAGE> buttons can be used in two modes.
1
Select the <CONF> button → [OPERATE] → [Transition] tab.
2
Set an item in [2nd Page Button] and [3rd Page Button] in the [Page Mode] column.
[Normal] Enabled only while the button is pressed.
[Page Lock] Enabled and disabled every time the button is pressed.
Assigning the SHIFT function to the KEY bus crosspoint buttons
1
Select the <CONF> button → [XPT ASSIGN] → [MainPanel]/[SubPanel1]/[SubPanel2] tab.
[MainPanel] tab Assigns the main control panel.
[SubPanel1] tab* Assigns the sub control panel 1 (the second Control Panel AV-HS60C1/AV-HS60C2).
[SubPanel2] tab* Assigns the sub control panel 2 (the third Control Panel AV-HS60C1/AV-HS60C2).
* This function will be available in V2.00.00 or higher.
2
Select the buttons to assign the SHIFT function from the button list in the left column.
f For details on the button assignment of the crosspoint area, refer to “Assigning signals to buttons” (page 118).
3
Select [2nd Page] or [3rd Page] from the signal list in the right column.
4
Select [Assign].
f The SHIFT function is assigned to the button selected in the step 2.
f Once the assignment is set on one page, the corresponding button on other pages works in a same way.
Selecting the bus mode
Select the A/B bus system or the ip‑op system (PGM/PST system).
1
Select the <CONF> button → [OPERATE] → [Transition] tab.
2
Select an item in [Bus Mode] in the [Bus Mode] column.
[A/B]
When the fader lever is at side A, the signals selected on the A bus are used as the source of the PGM bus.
When the fader lever is at side B, the signals selected on the B bus are used as the source of the PGM bus.
[PGM‑A/PST‑B]
Using a ip‑op system, the signals selected on the A bus are always used as the source of the PGM bus, and the
signals selected on the B bus are always used as the source of the PST bus.
[PGM‑B/PST‑A]
Using a ip‑op system, the signals selected on the B bus are always used as the source of the PGM bus, and the
signals selected on the A bus are always used as the source of the PST bus.
Setting the transition operation mode
Setting the time display unit
The time display unit used in this unit can be set as a second/frame basis or a frame basis.
1
Select the <CONF> button → [OPERATE] → [Transition] tab.
2
Select an item in [Time Unit] in the [Time Unit] column.
[Sec/Frame] Sets the time display unit as a second/frame basis.
[Frame] Sets the time display unit as a frame basis.
f When [Sec/Frame] is selected, the time that can be set differs depending on the system format.
- 59.94i: Max. 33s09f
- 59.94p: Max. 16s39f
