Chapter 8 System Menu — Setting the Main Frame AV‑HS60U1/AV‑HS60U2
2
Select an item in [Key1 Enable] to [Key4 Enable] in the [ME1 PVW]/[ME2 PVW] column.
[Off] Does not output signals.
[On] Outputs the preview signal of the corresponding keyer.
Setting the DSKPGM1/DSKPGM2 output
This unit has a DSKPGM1 output and a DSKPGM2 output. Set which line to assign DSK1 to DSK4.
1
Select the <SYS> button → [MAIN FRAME] → [DSK] tab.
2
Select an item in [Assign] in the [Config] column.
f Select the ME where DSK is assigned.
3
Select an item in [DSK1] to [DSK4] in the [Config] column.
[DSKPGM1] Assigns the corresponding DSK to the DSKPGM1 line.
[DSKPGM2] Assigns the corresponding DSK to the DSKPGM2 line.
Setting the DSKPVW1/DSKPVW2 output
Add the DSK preview on the background of PVW output of ME set in the step 2 in “Setting the DSKPGM1/DSKPGM2 output” (page 133). Lines to be
added follow the details set in the step
3 of “Setting the DSKPGM1/DSKPGM2 output” (page 133).
1
Select the <SYS> button → [MAIN FRAME] → [DSK] tab.
2
Select an item in [DSK1 Enable] to [DSK4 Enable] in the [DSK PVW] column.
[On] Outputs signals where the DSK preview is added.
[Off] Does not output signals.
Setting the SEL KEYPVW output
In the SEL KEYPVW output, the preview signal of the corresponding key is output when the <KEY1> to <KEY4> and <DSK1> to <DSK4> buttons on
the KEY operation area of each ME. The preview screen for chroma key adjustment is not output.
1
Select the <SYS> button → [MAIN FRAME] → [Sel KeyPVW] tab.
2
Select an item in [Key1 Enable] to [Key4 Enable] in the [ME1]/[ME2]/[DSK] column.
[On] Outputs the image where the key is combined when the button of the corresponding key is pressed.
[Off] Outputs the image where the key is not combined when the button of the corresponding key is pressed.
