– 154 –
Chapter 10 Specications — Specications
<LTC IN> terminal This is the LTC (linear time code) input terminal
f Connector: BNC
f Impedance: 1 kΩ
f Level: 1 to 2 V [p-p]
Video delay time 1 line (H) When the frame synchronizer is set to [Off], and the up-converter is set to [Off]
1 frame (F) When the frame synchronizer is set to on, or the up-converter is set to [On]
f When the signals have passed through PinP, DVE, MultiView, down-converter, or DVI-IN, a maximum delay of 1 frame is
applied in each case.
Control terminal
<LAN> terminal Compatible with 100Base-TX and AUTO-MDIX (For IP control)
f Connection cable: LAN cable (CAT5E), max. 100 m (328 ft), STP (Shielded Twisted Pair) cable recommended
f Connector: RJ-45
<PANEL> terminal Compatible with 100Base-TX and AUTO-MDIX (For Control Panel AV-HS60C1/AV-HS60C2 connection)
f Connection cable (supplied with AV-HS60C1/AV-HS60C2): LAN cable (CAT5E), straight cable, STP (Shielded Twisted
Pair), 10 m (32.8 ft)
f Connector: RJ-45
<COM1 (M)>/<COM2 (M)>/<COM3
(M)> terminals
RS-422 control terminal
For master connection for controlling external devices
f Connector: D-sub 9-pin (female) ×3, inch screw
<COM4 (M/S)> terminal RS-422 control terminal
For master/slave connection for controlling external devices
f Connector: D-sub 9-pin (female), inch screw
f Switchable between master connection and slave connection by the menu
<GPI IN> terminal GPI IN: 18 inputs, general-purpose, photocoupler sensing
ALARM OUT: 1 output, open collector output (negative logic)
f Connector: D-sub 25-pin (female), inch screw
<GPI OUT1>/<GPI OUT2>
terminals
GPI OUT: 48 outputs, selected from general purpose, tally
Open collector output
f Connector: D-sub 25-pin (female) ×2, inch screw
@@
NOTE
t Use with the same segment is recommended for the devices which are connected to the unit. If the unit is connected to the devices whose segments
are different, events dependent upon the settings inherent to the network equipment, for instance, may occur. Thoroughly check the connections with
the devices to which the unit will be connected prior to the start of operation.
Other
Ambient operating temperature
0°C to 40°C (32°F to 104°F)
Humidity 10% to 90% (no condensation)
Dimensions (W×H×D) 482 mm×132 mm×418 mm (18-31/32 inches×5-3/16 inches×16-15/32 inches) (excluding protrusions)
3RU
Mass
AV-HS60U1: Approx. 12.6 k] (27.8 lbs.) (excluding accessories)
AV-HS60U2: Approx. 13.5 k] (29.7 lbs.) (excluding accessories)
r For AV‑HS60U1E/AV‑HS60U2E
Inrush current, measured according to European standard EN55103-1, on initial switch-on: 3 A, after a supply interruption of 5 s: 35 A (Each mains
input)
