Chapter 5 Basic Operations — Wipe
f These can be set only when the target pattern is selected in the background.
Either operate the fader lever or press the <AUTO> button to check the wipe operation.
Example) When [X-Pos] is set to [−50], and [Y-Pos] is set to [−50]
The next screen (or key) appears from the bottom left, and wipes in towards the center of the screen.
8
Set [X‑Pos] and [Y‑Pos] in the [SQ] column.
f Set the start position of the next pattern waveform.
- SQ: 41, 42, 43, 44, 45
f The setting and operation are the same as those in the [Wipe] column.
9
Set [X‑Spin], [Y‑Spin], and [Z‑Spin] in the [Spin] column.
f Set the number of rotations to be linked with the amount of transition.
f This function will be available in V2.00.00 or higher.
Setting the trimming
Set the trimming and transition operations. The settings are applied to the background transition.
1
Select the <ME1>/<ME2> button → [BKGD] → [Position] tab.
2
Select an item in [Trim] in the [Trim] column.
f Set the trimming for the pattern waveforms of SQ, SL, and 3D.
[Off] Does not perform trimming.
[16:9]
Trims the edges around a source at a certain amount. This setting is used when a black border is seen around the
source.
The edges are trimmed at a certain amount when SD is selected as the system format.
[4:3]* Performs trimming in the 4:3 aspect ratio and releases the trimming when the transition is completed.
[4:3 Smooth]* Performs trimming in the 4:3 aspect ratio, and smoothly executes transition to the 16:9 video.
* Enabled when HD is selected as the system format.
3
Select an item in [4:3 Auto] in the [Trim] column.
f Set the target sources for automatic trimming ([4:3] or [4:3 Smooth]). Enabled when HD is selected as the system format.
[Off] All input sources are targeted for automatic trimming.
[On]
The input sources for which [Edge Crop] is selected in the up-converter setting are targeted for automatic trimming. Input
sources for which an item other than [Edge Crop] is selected are trimmed in [16:9].
Setting the 3D (turn page) effect
A lighting effect can be added to a wipe pattern. Alternatively, the parameters for turn page effect can be set.
f These effects can be set for background transitions and key transitions.
f Modify the following pattern waveforms.
- 3D: 99, 100, 101, 102
1
Select the <ME1>/<ME2> button → [BKGD] → [Modify] tab.
2
Select an item in [Light] in the [Pageturn] column.
[Off] Does not add the lighting effect.
[On] Adds the lighting effect.
3
Set [Size] in the [Pageturn] column.
f Set the size for reduction.
4
Set [Radius] in the [Pageturn] column.
f Set the radius for the turn page effect.
5
Set [Angle] in the [Pageturn] column.
f Set the direction for the turn page effect.
