Item
Transistor output type Relay output type
C14T C30T C60T C14R C30R C60R
(CH0)
(Note 1) Functions, channel numbers and I/O numbers used are set in the tool software.
(Note 2) I/O numbers used for each function should be allocated so that they do not overlap.
(Note 3) The pulse I/O cassette can be attached to the relay output type Control Unit only. (C14R: 1 piece,
C30R / C60R: Max. 2 pieces) When using two axes for the pulse output or two points for the PWM
output, use two pulse I/O cassettes.
1.1 Functions of Unit
1-4 WUME-FPXHPOSG-01
