Panasonic FP-XH Series

■
Notes on programming
● To change a speed during the JOG operation, rewrite the value of the positioning memory
(axis setting area) using a user program.
● The startup contact and flag numbers vary depending on channel numbers (axis numbers).
5.2.3 Speed Changes in JOG Operation
● The value of “JOG operation target speed” in the axis setting area is constantly monitored
while the operation is being executed. When the target speed is changed, it will be changed
with the same acceleration.
● The speed change is executed after the completion of acceleration/deceleration.
● The speed range in which the JOG operation can be set is 50Hz to 100kHz. When setting a
value smaller than 50 Hz, it is corrected to 50 Hz.
5.2 JOG Operation
5-8 WUME-FPXHPOSG-01
