Counting range of elapsed value (current value) area
Section Range
High-speed counter
control
K–2,147,483,648 to K2,147,483,647
10.1.3 Areas Used For High-speed Counter Function
The usable combinations vary according to the unit type.
■
List of used areas
Channel
No.
Transistor output
type
Relay output type
Control
active
flag
Elapsed
value
area
Target value
area
Input no. Input no.
Installation
position
Single-
phase
2-phase Single-
phase
2-phase
CH0 X0 X0, X1 X0 X0, X1
Control Unit
input
R9110
DT90300
DT90301
DT90302
DT90303
CH1 X1 - X1 -
Control Unit
input
R9111
DT90304
DT90305
DT90306
DT90307
CH2 X2 X2, X3 X2 X2, X3
Control Unit
input
R9112
DT90308
DT90309
DT90310
DT90311
CH3 X3 - X3 -
Control Unit
input
R9113
DT90312
DT90313
DT90314
DT90315
CH4 X4 X4, X5 X4 X4, X5
Control Unit
input
R9114
DT90316
DT90317
DT90318
DT90319
CH5 X5 - X5 -
Control Unit
input
R9115
DT90320
DT90321
DT90322
DT90323
CH6 X6 X6, X7 X6 X6, X7
Control Unit
input
R9116
DT90324
DT90325
DT90326
DT90327
