Panasonic FP-XH Series

4.2 Settings in Configurator PMX
4.2.1 Allocating Channels to be Used
Use the Configurator PMX to allocate used channels and applications. The following procedure
is explained on the condition that the FPWIN GR7 has already started.
1. Select Options>Positioning Table Settings from the menu bar.
”Configurator PMX” will be activated.
2. Select Channel setting>Used channel setting from the menu bar.
The “Used channel setting” dialog box will be displayed.
3.
Select the axes to be used and the usage, and press the [OK] button.
