Panasonic FP-XH Series

Mode Range
2-phase input
Individual input
Direction distinction
input
(Note 1) In the case of the input on the relay output type Control Unit, there is no combination of the individual
input and the direction distinction input.
10.1.5 Minimum Input Pulse Width
For the period T, the following minimum input pulse width is required.
10.1 Overview of High-speed Counter Function
WUME-FPXHPOSG-01 10-5
