11.1 Specifications
11.1.1 General Specifications
For details of the general specifications, refer to FP-XH User’s Manual (Basic).
11.1.2 Performance Specifications
■
High-speed counter / Pulse output / PWM output specifications
Item
Specifications
Relay type Transistor type
High-speed
counter
Control Unit input
Single-phase 8 channels or 2-phase
4 channels
Single-phase 8 channels: 10 kHz
each
2-phase 4 channels: 5 kHz each
Single-phase 8 channels or 2-phase
4 channels
High-speed single-phase (4
channels): 100 kHz each
Medium-speed single-phase (4
channels): 10 kHz each
High-speed 2-phase (2 channels):
50 kHz each
Medium-speed 2-phase (2
channels): 10 kHz each
Pulse I/O
cassette installed
C14: Single-phase 2 channels (2-
phase 1 channel)
C30/60: Single-phase 4 channels (2-
phase 2 channels)
With single-phase 2 channels (100
kHz), with 2-phase 1 channel (50
kHz)
With single-phase 4 channels (100
kHz), with 2-phase 2 channels (10
kHz)
Uninstallable
Pulse output /
PWM output
Control Unit
output
None
Pulse output: 100 kHz each
C14: 3 channels
C30: 4 channels
C60: 6 channels
PWM:
C14: 3 channels
C30 / 60: 4 channels
1 to 70 kHz (Resolution of 1000)
70001 to 100 kHz (Resolution of
100)
Pulse I/O
cassette installed
Pulse output: 100 kHz each
C14: 1 channel
C30 / 60: 2 channels
* With two cassettes installed
Uninstallable
PWM output: 2 channels
1 to 70 kHz (Resolution of 1000)
