3. Check if the home stop position shifts by repeating the JOG and home return operations.
Points to check
A shift may result depending on the position of near home input or home input and the
return speed.
4. If the home stopping position is shifted, change the position of near home input or reduce
the home return speed.
3.4.5 Checking Rotating and Moving Directions and Moving Distance
1. Execute the JOG operation to confirm the rotating direction and moving direction of the
motor.
Points to check
The rotating direction is determined according to the installation of the ball screw or the
“CW/CCW direction setting” of the parameter.
2. Check if the moving distance is that as designed by performing the JOG operation or
positioning operation.
Points to check
The moving distance is determined according to the pitch of the ball screw, deceleration
gear ratio or setting movement amount of the positioning data.
3.4 Confirming while the Power is ON
WUME-FPXHPOSG-01 3-7
