Panasonic FP-XH Series

■
Input signals of Control Unit
I/O
No.
Pulse output function
High-speed counter function
Count input
Reset input
Single-phase 2-phase
X0
CH0 J-point control positioning
control start input
CH0 Count input
CH0 Count input
-
X1
CH1 J-point control positioning
control start input
CH1 Count input -
X2 CH4 Home input CH2 Count input
CH2 Count input
-
X3 CH5 Home input CH3 Count input -
X4 CH0 Home input CH4 Count input
CH4 Count input
-
X5 CH1 Home input CH5 Count input -
X6 CH2 Home input CH6 Count input
CH6 Count input
CH0 Reset input
X7 CH3 Home input CH7 Count input CH2 Reset input
■
Output signals of Control Unit
I/O
No.
Pulse output function
PWM output function
Pulse output Deviation counter clear output
Y0 CH0 CW or pulse output - CH0 PWM output
Y1 CH0 CCW or sign output -
(Note 2)
Y2 CH1 CW or pulse output - CH1 PWM output
Y3 CH1 CCW or sign output -
(Note 2)
Y4 CH2 CW or pulse output CH0 (C14 type) CH2 PWM output
Y5 CH2 CCW or sign output CH1 (C14 type)
(Note 2)
Y6 CH3 CW or pulse output - CH3 PWM output
Y7 CH3 CCW or sign output -
(Note 2)
Y8 CH4 CW or pulse output CH0 (C30 type) -
Y9 CH4 CCW or sign output CH1 (C30 type) -
YA CH5 CW or pulse output CH2 (C30 type) -
YB CH5 CCW or sign output CH3 (C30 type) -
YC - CH0 (C60 type) -
YD - CH1 (C60 type) -
YE - -
YF - -
Y10 - CH2 (C60 type) -
Y11 - CH3 (C60 type) -
Y12 - CH4 (C60 type) -
Y13 - CH5 (C60 type) -
