Panasonic KX-NS500 Pc Programming Manual

Feature Guide References
2.6.6 Hot Line
Pickup Dial No.
Specifies the number to be dialled automatically after going off-hook when the Hot Line feature is active.
Value Range
Max. 32 digits (consisting of 0–9, *, #, T [Transfer], [ ] [Secret], P [Pause], and F [Flash])
Maintenance Console Location
12.2.1 PBX Configuration—[4-2-1] Extension—Portable Station—Extension Settings
Feature Guide References
2.6.6 Hot Line
Option 3
Extension Number
Indicates the extension number of the PS (reference only).
Value Range
Max. 5 digits (consisting of 0–9)
Maintenance Console Location
12.2.1 PBX Configuration—[4-2-1] Extension—Portable Station—Extension Settings
PC Programming Manual References
9.34 PBX Configuration—[1-2] Configuration—Portable Station— Extension No.
Extension Name
Specifies the name of the PS.
Value Range
Max. 20 characters
Maintenance Console Location
12.2.1 PBX Configuration—[4-2-1] Extension—Portable Station—Extension Settings
PC Programming Manual References
9.34 PBX Configuration—[1-2] Configuration—Portable Station— Extension Name
PC Programming Manual 691
12.2.1 PBX Configuration—[4-2-1] Extension—Portable Station—Extension Settings

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
