PennEngineering Haeger 824 WindowTouch-4e - Page 101

17-00001-C Page | 101
125.
126.
127.
COMPLETE INSERTIONS FOR STATION 1
YES: If adjustments are acceptable.
NO: If adjustments are NOT acceptable
and more adjustments are needed.
COMPLETE INSERTIONS FOR STATION 1
Upper tool in motion
• Check Part
• Touch on OK
• Touch on YES
• Ready for 3
rd
insertion
• Depress footswitch
Upper tool in motion
