PennEngineering Haeger 824 WindowTouch-4e - Type; Size; Unit of Measure; Fastener Length

17-00001-C Page | 72
46.
Type
47.
3. Size
Unit of Measure
48.
Fastener Length
Part Identification
2. Fastener Type:
➢ Blind Standoff
➢ Nut
➢ Standoff
➢ Stud/Pin
• Select Fastener Type
• Touch on STANDOFF
• Select Unit of Measure
• Touch on UNIFIED
• Select Part #
• Touch on CFSO-632-10
• Select Size
Identification #
• Touch on 632
• Select Length
• Touch on 10
4. Length: Select fastener length
5. Part #: Select part number from
database
3. Size:
➢ Metric or Unified
➢ Size Identification #
