17-00001-C Page | 31
Modular Auto Feed System (MAS 350)
Modular Auto Feed System (MAS): This system allows the operator to either run the MAS 350 at a
continuous vibration or an intermittent vibration. Continuous vibration is commonly used when running
the bowl out of hardware for a tooling change or for those small quantity hardware runs. Intermittent
vibration is most commonly used for normal insertion applications where you have good quantity of
hardware that will keep your multi module full at all times.
MAS 350 Bowl
• Fasteners vibrate up and
around the MAS bowl
• Automatically lining up the
fasteners at the doorway of
the multi module
MAS 350 Quick Mount Assembly
• Air is ejected, moving the fastener
through the tubing
• Positioning the fastener at the quick
mount assembly, ready for insertion
