Basic data sheet
YOUR Machine Model 824 WindowTouch 4e
Serial Number:
Year Manufactured:
Voltage:
Amperes:
Hertz (Machine):
Hertz (MAS):
Phase:
3
824 WindowTouch 4e Machine Matrix
Voltage
208/220
380/480
575
Amperage
17
9.6
6.1
Hertz
50 or 60
50 or 60
50 or 60
Phase
3
3
3
Noise Measurement Summary
Maximum Measured Value
Emissions Noise Sensitivity
In normal operation
A weighted pressure level
87db
C weighted pressure level
87db
-- For all locations, Noise protection is always recommended. --
Fluids & Pressure
Dimensions
Hydraulic Oil:*
AW Exxon Humble Hydraulic. H
Height:
90 in./2268 mm
ISO Viscosity:
32
Width:
32 in./813 mm
Capacity:
22 gallons/83 liters
Depth:
56 in./1422 mm
Max. Operating
Pressure:
2,450 psi/169 bar
Weight:
2900 lb./1131 kg
* Equivalent hydraulic oils may be used. It is the
machine owner’s responsibility to determine which
hydraulic oils in their area are equivalent to ISO 32.
