Quick mount mutli-shuttle
The Multi-Shuttle is a 1-piece quick mount tooling module with quick release mounting. The module has
an integrated built electrical/air supply connections and adjustable positive-locking alginment.
`
Step 2: Slide the multi-
shuttle into the positive
locking holder.
Step 1: Mount shuttle
tooling to the bottom of
multi-shuttle.
Step 3: Lock multi-
shuttle in place.
