17-00001-C Page | 139
Parts List – MAS 350 Bowl Assembly (cont’d)
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
1
SEE TABLE
BOWL, MAS 350
1
2
15-01702
DOWEL PIN, 4 x 10mm, HARDENED STEEL
2
3
15-02923
BLOCK, MOUNTING, MAS350
1
4
15-02924
LEVER, LOCKING, MAS 350
1
5
15-00273
1/4" TUBE STRAIGHT FITTING
2
6
15-02920
DOWEL, BUSHING #10, MAS 350
2
7
15-02921
WEIGHT, COUNTER, MAS 350
1
8
15-02922
WIPER, M8, M10 NUT, MAS 350
1
9
15-01961
DOWEL PIN, 3MM x 6MM
1
10
15-02914
DOOR, GATE, MAS 350
1
11
H-3711
O-RING, 1/2 X 3/8 X 1/16
2
12
15-03039
SCREW, M5X0.8 X 10MM, THUMB WITH
SHOULDER, STAINLESS
2
13
H-3738
SHCS, M5 x 0.8 x 12mm, BLACK OXIDE
2
14
11-00495
FLAT WASHER, M5, STEEL
3
15
15-01392
LOCK WASHER, M5, STEEL, ZINC PLATED
1
16
15-00484
SHCS, M5 x 0.8 x 20mm, STAINLESS STEEL
1
17
H-3899
FLAT WASHER, M4, STEEL
2
18
H-3745
BHCS, M4 x 0.7 x 8mm, STAINLESS STEEL
2
