Parts List – Quick Mount Upper Tool Assembly (cont’d)
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
1
15-02782
LOCKING AXLE, QUICK M., MULTI-SHUTTLE, WT (-4)
1
2
15-01674
SHCS, M3 x 0.5 x 25, STEEL, BLACK OXIDE
8
3
15-02790
CONNECTOR MALE, 1X AIR & 3X 24V, WT (-4)
2
4
15-02784
LEG LOCKING SIDE, QUICK MOUNT UPPER, WT (-4)
1
5
15-02785
LEG POSITION SIDE, QUICK MOUNT UPPER, WT (-4)
1
6
H-3738
SHCS, M5 x 0.8 x 12mm, BLACK OXIDE
2
7
15-01601
M6, WASHER, ZINC PLATED
1
8
11-00042
LEVER, LOCKING
1
9
11-00319
SHCS, M6 x 1.0 x 20MM, STAINLESS
2
10
H-3681
SPRING PLUNGER, M5, STEEL
1
11
15-41871
ASSY, MULTI-SHUTTLE 2, WT (-4)
1
12
15-02786
BODY, QUICK MOUNT UPPER TOOL, WT (-4)
1
13
11-00238
SHSS, M5 X 6, BLACK OXIDE
1
14
15-03079
NUT, HEX, M12 X 1.75, THIN, STAINLESS
1
