PennEngineering Haeger 824 WindowTouch-4e - Page 144

17-00001-C Page | 144
Parts List - Muti-Shuttle 2 Assembly (cont’d)
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
1
15-01870
SLIDE TABLE, MXS6 MULTISHUTTLE
1
2
15-02883
INSULATOR PLATE, MULTI-SHUTTLE 2
1
3
15-02881
ALIGNMENT PLATE, MULTI-SHUTTLE 2
1
4
15-02882
MOUNTING PLATE, MULTI-SHUTTLE 2
1
5
H-3935
FHCS, M4 x 0.7 x 12MM, BLACK OXIDE
7
6
15-01754
DOWEL PIN, 1/4" X 1/2", HARDENED STEEL
4
7
H-3871
SHSS, M5 x 0.7 x 12MM, BLACK OXIDE ALLOY STEEL
2
8
H-3815
SHCS, M6 x 1.0 x 12mm
3
9
15-02884
ALIGNMENT TRACK, MULTI-SHUTTLE 2
1
10
H-3738
SHCS, M5 x 0.8 x 12mm, BLACK OXIDE
2
11
15-01546
TUBE CONN MOUNT, MULTISHUTTLE
1
12
15-01974
M2.5-.45 X 10MM STEEL SHFS
4
13
15-01557
MOUNT, TUBE CONNECTOR, WT & OT (-3)
1
14
15-01852
MODULE PLATE, MULTISHUTTLE
1
15
H-3548
10-32X1/4 SET SCREW
1
16
H-3681
SPRING PLUNGER, M5, STEEL
1
17
15-02057
FHCS, M3 x 0.5 x 10mm
6
18
15-01558
LID, TUBE CONNECTOR, WT & OT (-3)
1
19
15-01709
FHCS, M2 x 0.4 x 4, BLACK OXIDE
1
20
15-02513
SPRING BLOCK, MULTISHUTTLE
1
21
15-01867
SHOCK ABSORBER, MULTISHUTTLE
1
22
H-3872
SHCS, M3 x 0.5 x 8MM, BLACK OXIDE
2
23
15-02885
T-BRACKET, MULTI-SHUTTLE 2
1
24
15-02789-1
END CAP, CONNECTOR, MULTI-SHUTTLE 2
2
25
15-02789
FEMALE, CONNECTOR, MULTI-SHUTTLE 2
2
26
15-01804
M4 X 18 SHCS
8
