PennEngineering Haeger 824 WindowTouch-4e - Page 146

17-00001-C Page | 146
Parts List – HMI Arm Assembly (cont’d)
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
1
15-02769
SUB-ASSY, HMI ARM
1
2
15-02827
USB CONNECTOR W/ CAP, WT & OT
1
3
H-1071
ELECTRICAL BUZZER
1
4
10-01327
FLAT WASHER, M12, ZINC PLATED
4
5
H-3785
LOCKWASHER, M12, STEEL, ZINC PLATED
4
6
H-3741
SHCS, M12 x 1.75 x 50MM, STEEL, BLACK OXIDE
4
7
15-03065
BUTTON, E-STOP, PUSH
1
8
15-03068
BUTTON, RED LED, PUSH
1
9
15-03067
BUTTON, GREEN LED, PUSH
1
10
15-02459
INTERFACE LABEL, WT & OT 4E
1
11
15-03066
SWITCH, KEY
1
