PennEngineering Haeger 824 WindowTouch-4e - Page 148

17-00001-C Page | 148
Parts List - TIS Assembly (cont’d)
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
1
15-00449
SHCS, M3 x 0.5 x 14MM, STAINLESS
2
2
15-01295
VINYL CAP BLUE
1
3
15-01296
VINYL CAP GREEN
1
4
15-01297
VINYL CAP RED
1
5
15-01298
VINYL CAP YELLOW
1
6
15-01585
COVER, BASE, TIS-2
1
7
15-01586
HUB, TIS-2 ROTATION
1
8
15-01587
LOWER TOOL ARM, TIS-2
3
9
15-01588
BASE COVER, ELECTRICAL, TIS-2
2
10
15-01589
COVER, LOWER TOOL ARM, TIS-2
1
11
15-01591
LOCKING PIN, ROTATION, TIS-2
1
12
15-01592
AXLE, TIS-2 ROTATION
1
13
15-01596
AUTOMATIC ARM, LOWER TOOL, TIS-2
1
14
15-01667
SHCS, M4 x 0.7 x 8mm, BLACK OXIDE STEEL
1
15
15-01668
DOWEL PIN, 3/16" x 1/2", HARDENED STEEL
8
16
15-01669
NEEDLE BEARING, 1"
1
17
15-01674
SHCS, M3 x 0.5 x 25, STEEL, BLACK OXIDE
4
18
15-01675
HCS, M10X1.5X25MM, STEEL, ZINC PLTD, 8.8
1
19
15-01677
BEARING WASHER, M10
2
20
15-01678
NEEDLE BEARING, M10
1
21
15-01681
SLEEVING, 3/8" ID X 3', BRAIDED POLYWSTER
1
22
15-01705
FHCS, M5 x 0.8 x 16mm, BLACK OXIDE, CLASS 10.9
4
23
15-02063
DOWEL PIN, 3/16" ID x 1/2" LG, ACETAL
1
24
15-02262
M2.5-.45 X 10MM STEEL SHFS
21
25
15-02493
WASHER, SERRATED, M10
1
26
15-02562
DOWEL PIN, 3/16" x 1/4"
1
