PennEngineering Haeger 824 WindowTouch-4e - Page 156

17-00001-C Page | 156
Parts List – Electric High/Low Voltage Cabinet Assembly (cont’d)
ITEM
NO.
PART
NUMBER
DESCRIPTION
QTY.
1
15-02734
CABINET, ELECTRICAL, WT (-4)
1
2
15-02744
LOW VOLTAGE PANEL, ELECTRICAL, WT (-4)
1
3
15-02745
HIGH VOLTAGE PANEL, ELECTRICAL, WT (-4)
1
4
15-01719
POWER SUPPLY 120W 5A 24VDC (CLEAN)
2
5
15-00715
SAFETY RELAY BOARD
1
6
15-02907
PLC RIO GALIL 47202
1
7
15-02773
CONTROLLER CARD, MAS 350,115V., 50-60 Hz. (optional)
1
8
15-00178
TRANSFORMER, 750 VA
1
9H
9L
15-03084
15-03083
High Voltage: Lenze VFD/ABB, 5HP 380- 480VAC
Low Voltage: Lenze VFD/ABB, 5HP 200-240VAC
1
10
15-01128
AMPLIFIER
1
11
10-01145
FUSE HOLDER 600V 30A DIN MOUNT
2
12
15-00137
CONTACTOR 24 VDC
1
13H
13L
10-00670
15-00139
High voltage: OVERLOAD RELAY
Low voltage: OVERLOAD RELAY
1
14
15-03064
EATON, AUXILLARY CONTACT 1NO-1NC
1
15H
15L
10-01154
15-00414
High Voltage: CIRCUIT BREAKER
Low Voltage: CIRCUIT BREAKER
1
16
15-00219
DISCONNECT SWITCH
1
17
15-02492
FAN GUARD 120 MM FAN
1
18
15-01752
GROUND STRIP, 21 PIN
1
19
15-03092
DISCONNECT GUARD
1
20
15-03210
INTAKE FILTER
1
21
15-03086
EMC Filter, 480VAC, 16A
1
OR
OR
Chose High OR Low Voltage
part # for your machine
Chose High OR Low Voltage
part # for your machine
OR
Chose High OR Low Voltage
part # for your machine
