17-00001-C Page | 159
Parts List – Hydraulic Reservoir Assembly (cont’d)
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
1
10-00087
BLACK RUBBER SEAL, 3/16 X 1
1
2
11-00319
SHCS, M6 x 1.0 x 20MM, STAINLESS
20
3
15-00226
LEVEL GAUGE WITHOUT THEMOMETER
1
4
15-00682
HHSC, M8 X 1.25 X 25mm LONG, ZINC PLATED
2
5
15-00758
RETURN FILTER ASSEMBLY
1
6
15-00782
H.S. RESERVOIR TOP
1
7
15-00784
RESERVOIR WELDMENT
1
8
SEE
824 HYDRAULIC COOLER ASSEMBLY
1
9
SEE
824 HYDRAULIC MANIFOLD SUBASSEMBLY
1
10
SEE
15-00785 - 824 HYDRAULIC MOTOR & PUMP ASSEMBLY
1
11
SEE
HYDRAULIC SUCTION FILTER ASSEMBLY
1
12
15-01102
HOSE SUCTION, 1" X 16.50" LONG
1
13
15-01103
HOSE SUCTION, 3/4" X 16.50" LONG
1
14
15-01106
HOSE RETURN, 1/2" X 17.25" LONG
1
15
15-01107
HOSE, COOLER TO MANIFOLD, 3/4" X 13.75" LONG
1
16
15-01108
HOSE PRESSURE,, 3/4" X 30.75" LONG
1
17
15-01114
HOSE, COOLER TO TANK, 3/4" X 37.00" LONG
1
18
15-01158
HOSE PRESSURE, 5/8" X 32.25" LONG
1
19
15-01165
NUT, M10 HEX FLANGE
2
20
15-01183
FITTING, 3/4" MALE PIPE TO 1-5/16" MALE JIC
1
21
15-01185
FITTING, MJ-MP 90 8-12
1
22
15-01393
LOCK WASHER, M6, DIN127 ZINC
20
23
15-01469
HEX HEAD BOLT M8 X 40mm STEEL
4
24
15-01601
M6, WASHER, ZINC PLATED
14
25
15-02166
DRAIN PLUG, O-RING BOSS 1/2"
1
26
H-3596
FLATWASHER, 1/4"
6
