➢ NEVER tamper with any part of this machine’s electrical
system unless you are a trained electrician and
thoroughly understand this machine’s electrical
schematic.
➢ Check to make sure that the electrical power supply for
this machine has been disconnected at the supply
source before doing any work on the machine’s
electrical system.
Adjusting the Wiring if the Previous Step Failed
1. Disconnect the machine from its electrical power supply at the supply source.
2. After disconnecting the machine from its electrical power supply at the supply source, turn the
machine’s Main Disconnect Switch to the Off position.
3. Using the special Electrical latch key, open the door of the Main Electrical Control Cabinet.
4. Reverse the incoming electrical leads on terminals L2 and L3 of the Main Disconnect Switch (see
electrical schematic)
5. Close and latch the door using the special key.
6. Turn the machine’s Main Disconnect Switch to the On position.
7. Have someone watch the motor in the base of the machine when you turn the machine on.
The motor has an orange arrow indicating the correct motor rotation. Press the On Button.
The green light in the switch will turn on and the machine’s motor will start.
8. If the motor turned the same direction as the arrow, install the Side Panels on the Machine
Base. The machine is now ready for use.
9. If the motor did not turn in the same direction as the arrow contact your Haeger
Representative for instructions.
Do not operate the machine without both the Upper and Lower
Tools properly locked in place with the correct set screws
and/or Quick Change Lever.
In this manual, the use of the terms left and right refers to
the machine operator’s left and right when they are standing in
front of the machine, facing the work area between the Upper
Tool Holder and Lower Tool Holder.
