PennEngineering Haeger 824 WindowTouch-4e - Page 86

17-00001-C Page | 86
88.
89.
90.
2. Amount of Insertions in Group
• Touch on OK
• Touch on 2 for the
# of fasteners to be
inserted
3. Location: Images can be selected
from two different locations:
➢ Pre-Used: Saved images previously
used.
• Select the same image from
Previously Used Images
• Touch on IMAGE
• Select a part image for
hardware insertion
• Touch on IMAGE
3. Image: This icon associates a part image
with the insertion group.
