17-00001-C Page | 89

97.

98.

99.

• Touch on USE

• Touch on

INSERTION 1

• Touch on

INSERTION 2

• Touch on NEW

INSERTION 3

• After Touching on NEW INSERTION 3, this

question will popup… Add Extra Insertion?

• Touch on YES
