188
Changing Additional Settings
8
4
Press the 4 button.
5
Press the 3 button.
The screen that was displayed before selecting the menu appears again.
Pixel Mapping is a function for mapping out and correcting defective pixels
in the CMOS sensor.
Attach a 01 STANDARD PRIME or 02 STANDARD ZOOM lens to the
camera.
1
Select [Pixel Mapping] in the [R Set-up 3] menu, and press
the four-way controller (5).
The [Pixel Mapping] screen appears.
2
Press the four-way controller (2) to select [Pixel
Mapping], and press the 4 button.
Defective pixels are mapped out and corrected, and the screen that was
displayed before selecting the menu appears again.
Correcting Defective Pixels in the CMOS Sensor
(Pixel Mapping)
• It takes about 30 seconds to correct the defective pixels.
• When the battery level is low, [Not enough battery power remaining to
activate Pixel Mapping] is displayed on the monitor. Use the AC adapter kit
(optional) or install a fully charged battery.
To Next Page
