39
Getting Started
2
1
Slide the battery cover in the
direction of the arrow, and then
lift it to open (1→2).
2
Insert the battery until it locks
into place with the 2 mark facing
toward the lens.
To remove the battery, push the battery
lock lever in the direction of the arrow (3)
with your finger.
3
Close the battery cover, and then
slide it in the direction of the
arrow (4→5).
You can confirm remaining battery level by checking the display on the
monitor.
Battery Level Indicator
Monitor Display Battery Level
w (Green) Battery is full.
x (Green) Battery is close to full.
y (Yellow) Battery is running low.
F (Red) Battery is almost empty.
[Battery depleted] The camera turns off after displaying the message.
2
1
3
4
5
